ABB Midwest Electric U065 Series Pullout Single Phase Non-fused Air Conditioner Disconnects 60 A NEMA 3R 120/240 V
Mfg #:
U065NA1
BOR #:
148085
Midwest's combination A/C disconnects are designed to satisfy code requirements for use with an A/C unit and outdoor GFCI receptacle. The code change requiring an in-use weatherproof cover on the outdoor GFCI is met since the combination units are NEMA 3R
- Door has padlock provisions to prevent unauthorized access
- Heavy galvanized G90 steel with highest quality electro-deposition finish resists corrosion and fading
- Single-phase
- NEMA 3R
- UL & cUL Listed
- New UL approved 15 Amp GFCI receptacle included
| Brand | ABB Midwest Electric |
| NEMA Rating | NEMA 3R |
| Voltage | 120/240 V |
| Number of Phases | 1 Phase |
| Wire Size | (1) 14 - 2 AWG |
| Material | Steel |
| Amperage | 60 A |
| Enclosure Type | N3R Enclosure |
| Height | 7 in |
| Width | 5 in |
| Depth | 2.2 in |
| Disconnect Type | Non-fused |
| ABB Midwest Electric Specification Sheet | Specification Sheet |
|
