Square D QO™ QOXD Plug-in Miniature Circuit Breakers 16 A 240/415 VAC 3 kAIC 2 Pole 1 Phase
Mfg #:
QOXD216
BOR #:
1315583
| Brand | Square D |
| Wire Size | 8 - 2 AWG |
| Circuit Breaker Type | Miniature Breaker (Standard) |
| Includes | Box Lugs |
| Trip Type | Thermal Magnetic |
| Net Weight | 0.268 kg |
| Indicator Type | Trip Flag |
| Number of Poles | 2 Pole |
| Interrupting Rating | 3 kAIC |
| Amperage | 16 A |
| Voltage | 240/415 VAC |
| Number of Spaces | 2 Space |
| Number of Phases | 1 Phase |
| Series | QO™ QOXD |
| Mounting Type | Plug-in |
| Product Certifications | IEC |
| Square D Specification Sheet | Specification Sheet |
|
| files?p_enDocType=Catalog&p_File_Name=SD_0100CT1902_SEC-07.pdf | Catalog |
|
| Square D Combination AFCI Circuit Breakers Brochure - 0700BR1202 (pdf) | Brochure |
|
| A Guide to Your Square D Electrical Distribution System - Brochure - 0102BR0201 (pdf) | Brochure |
|
