Square D Surgelogic® Surge Protection Devices Gray painted sheet steel 208Y/120 VAC NEMA 1
Mfg #:
SSP02EMA24
BOR #:
3400093
Surgelogic® Surge Protection Modules
| Brand | Square D |
| MCOV | 150 V |
| Mounting Type | surface |
| Number of Poles | 3 Pole |
| Material | Gray painted sheet steel |
| Voltage | 208Y/120 VAC |
| Connection Type | 10 - 2 AWG Copper Lugs |
| Number of Phases | 3 phase |
| Short-Circuit Current | 200 kA |
| NEMA Rating | NEMA 1 |
| Series | Surgelogic™ EMA |
| Type | Surge protection device, Type 1 |
| Square D Surgelogic EMA EBA Surge Protective Devices Catalog - 1310CT0202 (pdf) | Catalog |
|
| Type EMA, Certificate, UL - UL_E314042_T1_SSP02EMA10-24Certification (pdf) | Compliance |
|
| Surgelogic EMA Surge Protective Device (SPD) Installation and User Guide - 8222-0014 (pdf) | Installation and Instruction Manuals |
|
| Type EMA, Certificate, UL - UL_E314042_T2_SSP02EMA10-24Certification (pdf) | Compliance |
|
