Leviton CR20 Series Duplex Receptacles 20 A 125 V 2P3W 5-20R Commercial Specification Grade Orange

PrimaryProductImage
PrimaryProductImage
Logo
Mfg #: CR20O
BOR #: 1289172
View all 8 in product family
Looking for prices?
Sign In
Create an Account

Shallow design for maximum wiring room in box

  • Convenient washer-type break-off plaster ears for best flush alignment
  • Heavy-gauge, rust-resistant steel mounting strap
  • Captive mounting screws for fast installation where applicable
  • UL listed 498
See More
Product can be ordered only in multiples of
Specifications
Brand Leviton
Pole/Wire 2P3W
Voltage 125 V
NEMA Configuration 5-20R
Ground Type Self-grounding
Design Duplex
Color Orange
Device Configuration Duplex
NEMA Rating WD-1 & WD-6
Material Thermoplastic
Number of Phases 1 Phase
Grade Commercial Specification Grade
Mounting Type Screw
Wire Size 14 - 10 AWG
Wiring Method Back and Side Wired
Amperage 20 A
Related Documents
Straight Blade Receptacle Catalog Q 1101H Catalog
Leviton Specification Sheet Specification Sheet
Related Videos
How to install a Leviton CR20 Receptacle
