Leviton 5801 Series Single Receptacles 20 A 125 V 2P3W 5-20R Commercial Specification Grade Brown

Mfg #: 5801

BOR #: 119379

View all 5 in product family

Looking for prices?

Create an Account

Available in a wide variety of configurations, including isolated ground, tamper-resistant, etc., these Commercial Grade devices are the electrical contractor's choice for use in hotels, schools, hospitals and commercial office buildings

All power contacts are triple wipe for maximum conductivity and plug retention - except CR series
Convenient washer-type break-off plaster ears for best flush alignment
Heavy-gauge, rust-resistant steel mounting strap
UL listed 498
Captive mounting screws for fast installation where applicable

Product can be ordered only in multiples of

Specifications

Brand	Leviton
Pole/Wire	2P3W
Voltage	125 V
NEMA Configuration	5-20R
Ground Type	Grounding
Color	Brown
Device Configuration	Single Receptacle
NEMA Rating	WD-2 WD-6
Material	Nylon
Number of Phases	1 Phase
Grade	Commercial Specification Grade
Mounting Type	Screw
Wire Size	14 - 10 AWG
Wiring Method	Side Wired
Amperage	20 A

Straight Blade Receptacle Catalog Q 1101H	Catalog
Leviton Specification Sheet	Specification Sheet
