Hubbell Wiring Straight Blade Single Receptacles 30 A 125 V 2P3W 5-30R Industrial Dry Location Black
Mfg #:
HBL9308
BOR #:
136467
| Brand | Hubbell Wiring |
| Pole/Wire | 2P3W |
| Voltage | 125 V |
| NEMA Configuration | 5-30R |
| Ground Type | Grounding |
| Color | Black |
| Environmental Condition | Dry Location |
| Illumination | No Illumination |
| Device Configuration | Single Receptacle |
| Insulation | Uninsulated |
| Hazardous Rated | Not Hazardous Rated |
| Material | Reinforced Thermoplastic (RTP) |
| Number of Phases | 1 Phase |
| IP Rating | IP20 |
| Grade | Industrial |
| Mounting Type | Screw |
| Wire Size | 12 - 4 AWG |
| Number of Poles | 2 Pole |
| Wiring Method | Back and Side Wired |
| Amperage | 30 A |
| Catalog Full Asset Reference | Catalog |
|
| Installation Manuals Asset Reference | Installation and Instruction Manuals |
|
| Hubbell Wiring Specification Sheet | Specification Sheet |
|
| Catalog Page Asset Reference 1 | Catalog |
|
| Catalog Page Asset Reference 2 | Catalog |
|
