Hubbell Wiring Straight Locking Plugs 20 A 347/600 V 4P4W L20-20P Insulated Twist-Lock® Insulgrip® Dry Location
Mfg #:
HBL2461
BOR #:
601797
| Brand | Hubbell Wiring |
| Device Control Style | Locking |
| Ground Type | Non-grounding |
| Pole/Wire | 4P4W |
| NEMA Configuration | L20-20P |
| Plug/Connector Style | Non-shrouded |
| Design | Straight |
| Voltage | 347/600 V |
| IP Rating | IP20 |
| Color | Black/White |
| Insulation | Insulated |
| Device Configuration | Male |
| Length | 2-3/4 in |
| Wiring Method | Screw |
| Environmental Condition | Dry Location |
| Number of Phases | 3 Phase |
| Amperage | 20 A |
| Wire Size | 16 - 8 AWG |
| Mounting Type | Cord |
| Material | Composite |
| Grade | Industrial |
| Series | Twist-Lock® Insulgrip® |
| Plug/Connector Type | Plug |
| Catalog Page Asset Reference | Catalog |
|
| Catalog Full Asset Reference | Catalog |
|
| Hubbell Wiring Specification Sheet | Specification Sheet |
|
| Installation Manuals Asset Reference | Installation and Instruction Manuals |
|
Twist Lock Devices
Hubbell Insulgrip® Twist-Lock’s rugged construction features highly engineered materials, roomy...
Twist Lock Devices
Hubbell Insulgrip® Twist-Lock’s rugged construction features highly engineered materials, roomy...
