RITTAL Standard Push Button Enclosures NEMA 12/13/4
Mfg #:
8017647
BOR #:
2353971
These NEMA rated boxes are designed for indoor use to house push-buttons, selector switches, pilot lights, etc. and to protect such equipment against dirt, dust and sprayed water, oil or coolant
- Accepts 22.5 mm and 30.5 mm devices
- Available in sizes from a single position to 42 hole positions
- Certifications include: UL TYPE 4, 12 & 13 protection rated, UL file: E118617, UL, cUL
- Enclosures and covers are made from 14-gauge carbon steel for strength and durabilit
- Interior and exterior finish is a polyester-urethane powder coat over phosphatized surface, color is RAL 7035 (light gray)
- Several of these enclosures can be mounted onto a Rittal column and base for use as an operator station
| Brand | Rittal |
| Depth | 2.7 in |
| Number of Holes | 3 Hole |
| Includes | Cover screws, captive Wall Mounting Brackets |
| Mounting Type | Wall |
| Width | 3.2 in |
| Height | 8 in |
| Color | Light Gray |
| Material | Carbon Steel |
| NEMA Rating | NEMA 12/13/4 |
| Rittal Specification Sheet | Specification Sheet |
|
